| Main features: | ||||||||||
| 1) Private mould, slim and elegant appearance; | ||||||||||
| 2) Module design - easy maintenance; | ||||||||||
| 3) Flat honeycomb design - good heat dissipation; | ||||||||||
| 4) High Luminous Efficiency: 120-130 lm/W; | ||||||||||
| 5) Different Lens Angle is available and optional. | ||||||||||
| Item No. | Dimension （mm） |
Voltage | Power（W) | Color Temp. | Light Source | LED Quantity (PCS) |
Luminous Flux LM（±10%） |
Lens Angle | Package Size(mm) | Weight(Kg) |
| 120Lm/W （12*1 lens） | ||||||||||
| AC100-277V Sosen/Meanwell HBG | Warm white: 2800-3500K Netural white: 3800~4500K Pure white: 5500~6500K |
3030 Ra≥80 |
12*1（50*50mm)，30°/60°/90°/120°/TYPE3 | |||||||
| HB-S3-100 | φ290*153 | 100 | 108 | 12000 | 312*312*137 | 2.8 | ||||
| HB-S3-150 | φ362*153 | 150 | 192 | 20000 | 384*384*137 | 3.4 | ||||
| HB-S3-200 | φ400*163 | 200 | 240 | 27000 | 384*384*137 | 3.4 | ||||
| HB-S3-240 | φ400*163 | 240 | 240 | 29000 | 422*422*137 | 4.0 | ||||
